Conveyor Roller
Conveyor Components
  • Conveyor ComponentsConveyor Components

Conveyor Components

Hubei Xin Aneng as the professional manufacturer of high quality Conveyor Components with guarantee 30,000hrs in normal working conditions. At XAN, we focus on production management, down to the cleanliness of the factory floor. We believe that production management reflects product quality. Only by holding ourselves to strict standards can we produce high-quality products and serve our customers effectively.

The main technical parameters of The Conveyor Components include the following aspects:

1. Diameter: The diameter of The Conveyor Components is one of its most critical parameters, which determines the load-bearing capacity and stability of the roller. Common wheel diameter sizes include 38mm, 50mm, 60mm, 76mm, 89mm, 102mm, etc. There are also larger diameters such as 108mm, 133mm, 159mm, 194mm, 219mm, etc. The larger the diameter, the stronger the load-bearing capacity and the wider the scope of application.


2. Length: The length of The Conveyor components is generally between 200mm and 2000mm, but there are also special size rollers, such as steel rollers with a length of up to 4000mm. The length mainly affects the transportation capacity and scope of application of the roller. Longer rollers are suitable for larger logistics equipment and occasions where the goods are transported for a long time.


3. Width: The width of The Conveyor Components is generally 300mm, 400mm, 500mm, 600mm, 700mm, etc. Larger rollers can also reach 1200mm. The width mainly determines the load-bearing capacity and application range of the roller. Generally speaking, the roller with a larger width has a stronger load-bearing capacity, but it is not suitable for use in a small working space.


4. Material: The material of The Conveyor Components is also one of its important technical parameters. Common materials include Q235, 45# steel, etc. Idlers made of different materials have different wear resistance, load-bearing capacity and service life.


5. Arrangement spacing: Different types of The Conveyor Components have different arrangement spacing requirements. For example, the arrangement spacing of trough rollers shall not be greater than 1200mm, and one set of upper-centering rollers shall be provided for every 10 groups of trough rollers (normal spacing arrangement); the arrangement spacing of parallel rollers shall not be greater than 3000mm, and every 8 groups of return rollers shall be arranged. There is a set of lower centering rollers; the buffer rollers are installed at the loading area of the belt conveyor to alleviate the impact of materials on the conveyor belt. The buffer rollers under the guide trough are arranged at a distance of ≤600mm.




6. Rotation resistance: The rotation resistance of The Conveyor Components is also one of its important technical parameters. It reflects the resistance of the roller during rotation. The smaller the rotation resistance of the roller, the higher its operating efficiency and the lower its energy consumption.


Diameter
mm

Length (mm)  Roller for conveyors

Bearing No.

89

180

190

200

235

240

250

275

280

305

204

215

350

375

380

455

465

600

750

950

1150

108

190

200

240

250

305

315

360

375

380

204.205.305.306

455

465

525

530

600

700

750

790

800

950

1150

1400

1600

133

305

375

380

455

465

525

530

600

670

205.305.306

700

750

790

800

900

950

1000

1100

1150

1400

1600

1800

2000

2200

159

375

380

455

465

525

530

600

700

750

305.306.308

790

800

900

1000

1050

1100

1120

1150

1180

1250

1400

1500

1600

1700

1800

2000

2200

2500

2800

3000

3150

Production Equipment in Hubei Xin Aneng Conveyor Machinery Co., Ltd:

No.

Machine name

Inspection item

1

Ultrasonic flaw detector

welding seam, ultrasonic inspection of steel plates

2

Roller axial displacement measuring instrument

Detecting axial displacement

3

Roller resistance measuring instrument

Detecting rotational resistance

4

Roller waterproof test bench

Testing waterproof performance

5

Roller axial bearing test bench

Measure axial bearing capacity

6

Static balance test bench

Check the static balance of the drum

7

Coaxiality test bench

Check the coaxiality of the roller

8

Coating thickness gauge

Measure the thickness of the paint

9

Sound level meter

Measure noise level

10

Tachometer

easure rotational speed

The Cefiticates of Hubei Xin Aneng Conveyor Machinery Co., Ltd:

Hubei Xin Aneng Conveyor Machinery Co., Ltd always treat excellence as a habit
