Conveyor Roller
Roller for Conveyors

Roller for Conveyors

Hubei Xin Aneng's manufacture Roller for Conveyors for more than 33 years. We control products quality through raw material procurement system, factory management system, production equipment system, testing equipment system, etc. We mainly provide complete belt conveyor solution and have very strong design and production capabilities.

Since 1990, Mr. Guo has been dedicated to the bulk material handling industry, leading the factory to rapid growth. In just 5 years, we achieved what others took over 20 years to accomplish. Mr. Guo steadfastly avoided investments in real estate, cars, or any other ventures. For 33 years, he has poured all his efforts and energy into perfecting every conveyor roller.

The installation steps of Roller for conveyors are as follows:

1. Installation positioning: Predetermine the installation position of the Roller for conveyors on the belt. Usually, a roller group is installed at a certain distance (such as every meter or every two meters). Use a measuring tool to align and mark the position of the roller axis.


2. Install the bracket: Install the roller bracket below or above the belt and fix the roller on it. Note that the bracket should be parallel to the running direction of the belt and firmly connected through expansion bolts or other fasteners.


3.Install the roller: Place the polymer roller into the bracket along the marked axis line to ensure its level and parallelism to avoid belt deviation due to tilt. Then, use a wrench or socket to tighten the fixing screws between the roller and the bracket.


4.Connecting supporting equipment: connect the transition components (if any) between adjacent rollers to achieve a smooth transition of the belt. At the same time, connect with the driving device (reducer, motor, etc.) and adjust the tension to ensure normal operation of the belt.


5. Inspection and debugging: After the installation is completed, start the belt and check whether each roller rotates flexibly and whether the belt deviates. If there is any abnormality, it should be adjusted in time.

During the installation process, you need to pay attention to the following details:

1. The fixing method of the rollers should comply with relevant installation standards and ensure the firmness and stability of the rollers.


2. The distance between rollers should be adjusted according to the size and speed of the conveyed material. Generally speaking, the distance between rollers should be smaller than the maximum size of the material to avoid material jamming. At the same time, the distance between rollers should be as uniform as possible to ensure stable transportation of materials.


3. The cooperation between the roller and the conveyor belt needs to be maintained well, otherwise its sealing and transmission effects will be affected.


4.Before installing the roller, the components and installation location should be carefully cleaned to ensure the quality and effectiveness of the installation.


5.In order to ensure the normal operation of the rollers, appropriate lubrication methods should be selected and maintained and replaced regularly.

Diameter
mm

Length (mm)

Bearing No.

89

180

190

200

235

240

250

275

280

305

204

215

350

375

380

455

465

600

750

950

1150

108

190

200

240

250

305

315

360

375

380

204.205.305.306

455

465

525

530

600

700

750

790

800

950

1150

1400

1600

133

305

375

380

455

465

525

530

600

670

205.305.306

700

750

790

800

900

950

1000

1100

1150

1400

1600

1800

2000

2200

159

375

380

455

465

525

530

600

700

750

305.306.308

790

800

900

1000

1050

1100

1120

1150

1180

1250

1400

1500

1600

1700

1800

2000

2200

2500

2800

3000

3150

Production Equipment in Hubei Xin Aneng Conveyor Machinery Co., Ltd:

No.

Machine name

Inspection item

1

Ultrasonic flaw detector

welding seam, ultrasonic inspection of steel plates

2

Roller axial displacement measuring instrument

Detecting axial displacement

3

Roller resistance measuring instrument

Detecting rotational resistance

4

Roller waterproof test bench

Testing waterproof performance

5

Roller axial bearing test bench

Measure axial bearing capacity

6

Static balance test bench

Check the static balance of the drum

7

Coaxiality test bench

Check the coaxiality of the roller

8

Coating thickness gauge

Measure the thickness of the paint

9

Sound level meter

Measure noise level

10

Tachometer

easure rotational speed

The Cefiticates of Hubei Xin Aneng Conveyor Machinery Co., Ltd:

Hubei Xin Aneng Conveyor Machinery Co., Ltd always treat excellence as a habit
