Due to structural characteristics driven by cost optimization, steel cord conveyor belts are still prone to specific faults during actual operation. Mastering the targeted troubleshooting logic for such products is the core guarantee for stable operation of low-cost conveying systems.
This is the most common fault unique to this type of product, manifesting as localized exposure of internal steel cords on the belt surface, or wire pull-out and fraying at the belt edges.
Insufficient cover thickness: To control costs, cost-driven "agreement-spec" budget products usually have a cover layer 10%–20% thinner than standard products, with weaker wear and penetration resistance. Long-term operation wears through the cover and directly exposes the steel cords.
Defects in splice vulcanization process: Low-priced products often have a thinner zinc coating on the steel cord surface. If the temperature and pressure are not properly controlled during on-site vulcanization, the bonding strength between the steel cords and rubber will be insufficient, leading to cord pull-out from the splice during operation.
Lack of edge protection: To cut costs, edge designs such as oil-resistant and wear-resistant rubber strips are often omitted. After friction between the belt edge and the frame, the belt wears directly down to the steel cord layer.
Local reinforcement repair: When small-area steel cord exposure is found, immediately remove rust from the exposed area, and use dedicated steel cord conveyor belt cold-vulcanizing adhesive + wear-resistant rubber sheet to seal the surface, preventing water vapor intrusion that causes cord corrosion and breakage.
Standardize splice construction: Splices for such products must adopt the vulcanization parameters specified by the manufacturer. Before vulcanization, polish off floating rust on the steel cord surface, apply 3 coats of dedicated adhesive, and prohibit simplified processes.
Install edge guard plates: Install replaceable polyurethane guard plates at the contact position between the frame and the belt edge to avoid direct friction against the belt edge.
It manifests as the conveyor belt becoming looser over time, and the tensioning device fails to eliminate slippage even after its full adjustment stroke is exhausted.
Insufficient pre-tension of steel cords: Budget products are not subject to sufficient pre-stretching treatment on the steel cords before leaving the factory, so plastic deformation occurs after being put into operation under load, increasing the overall length.
Small margin of rated tensile force: Under cost-oriented design, the safety factor of such products usually takes the lower limit. When the stress of the steel cords exceeds the elastic limit during heavy-load operation, irreversible elongation occurs.
Poor adaptability of tensioning device: Some projects select simplified tensioning mechanisms to match cheap conveyor belts, with insufficient reserved adjustment stroke, which cannot offset the normal elongation of the belt body.
Cut and re-splice: If the elongation exceeds 0.5% of the total belt length, cut off a section of the belt and make a new splice. It is strictly prohibited to force operation by over-tensioning to avoid belt breakage risks.
Stepwise loading commissioning: Before putting a new belt into service, run it empty for 24 hours first, then gradually load it at 50%, 80%, and 100% of the rated load to release early plastic deformation.
Upgrade tensioning configuration: Replace the fixed tensioning system with an automatic hydraulic tensioning system to compensate for belt elongation in real time, avoiding failures caused by delayed manual adjustment.
It manifests as bulging and cracks at the splice, and in severe cases, the entire splice separates from the belt body.
Degraded rubber performance: The vulcanized rubber supplied with cost-driven agreement-spec budget products is usually ordinary natural rubber, with poor heat resistance and aging resistance, leading to aging failure of the bonding interface after long-term operation.
Steel cord arrangement deviation: Low-priced products have insufficient uniformity in steel cord arrangement during production. During splice operation, local stress concentration occurs on the cords, tearing the rubber layer.
Erosion by environmental media: If conveyed materials contain acids, alkalis, or oils, they will penetrate to the splice interface and damage the bonding strength. Such products themselves have limited margin in chemical-resistant formulas, so they are more obviously affected.
Use high-performance rubber: During splice vulcanization, special splice rubber matching the performance of the original factory cover must be used; general low-price rubber substitutes are prohibited.
Strengthen splice inspection: Check the splice for bulges and water seepage marks every shift. If tiny cracks are found, immediately carry out edge sealing and waterproof treatment to prevent further expansion.
Redundant splice design: For critical lines, a "double-step" vulcanization structure can be adopted for splices, which increases the tensile resistance by 30% compared with conventional single-step splices, making up for the inherent strength shortcoming of the product itself.
Targeted Preventive Maintenance: Operation Strategies Matching Low-Cost Products
For agreement-spec budget steel cord conveyor belts, the general maintenance rhythm needs to be adjusted, using high-frequency, low-cost inspections to avoid major failures:
| Frequency | Inspection Content |
| Daily inspection | Focus on checking cover wear at belt edges, splices, and feeding points; measure residual cover thickness, and arrange repairs immediately if it is less than 2 mm. |
| Weekly check | Detect whether the splice has displacement or cracking, verify the remaining stroke of the tensioning device, and plan belt cutting and splicing in advance if the remaining stroke is less than 1/3 of the total stroke. |
| Monthly maintenance | Randomly sample the steel cords: cut a small sample from the non-working area of the belt, peel it to check for cord corrosion. If large-area red rust appears, evaluate the overall replacement cycle. |
| Quarterly verification | Use a portable X-ray flaw detector to scan the steel cord arrangement inside the splice, to identify hidden risks such as delamination and broken wires in advance. |
-
